Fluorine-free water repellent coating (In Development)
We offer a lineup of fluorine-free coating material development products designed to address PFAS regulations.
We continue to develop materials with properties tailored to meet various performance requirements.
Characteristics
| Name | Characteristics |
|---|---|
| In Development Dev-01Series |
A development product with high scratch resistance, water repellency, oil repellency, and slip properties. Heating is requiredto achieve solvent resistance. |
| In Development Dev-02Series |
An upgraded version of the existing product (OR-510). Excellent durability, maintainsinitial performance, and is curable atroom temperature(no heating required). |
| In Development Dev-03Series |
A development productoptimized for scratch resistance. Heating is required to achive solvent resistance, and oil repellency is limited. |
| Existing Product OR-510 |
An existing fluorine-free (PFAS-free) coating that provides water repellency, oil repellency, slip properties, and solvent resistance. |
Basic Performance
| Dev-03-002 | Dev-02-003 | Dev-01-001 | OR-510 | ||
|---|---|---|---|---|---|
| C.A. [°] (2.5μL) |
Water | 108 | 109 | 102 | 108 |
| Hexadecane | 33 | 37 | 20 | 37 | |
| S.A. [°] | Water (30μL) | 3 | 1 | 20 | 1 |
| Dynamic Friction Coefficient (Condition : 50g/cm²) |
0.15 | 0.10 | 0.40 | 0.10 | |
| Refractive Index (550nm) | 1.44 | 1.45 | 1.45 | 1.44 | |
| Performance Retention (Durability) | 100% | 100% | 100% | 23% | |
| Average C.A. After Durability Test | 101 | 104 | 101 | 96 | |
| Solvent Resistance (Ethanol, IPA, etc) | No※ | Yes | No※ | Yes | |
| Product Form | Al₂O₃ Pellet |
- | - | - | Available |
| Cu cup | Available | Available | Available | Available | |
| The official name will be decided once mass production is confirmed. | |||||
Substrates : φ30mm Borosilicate Glass (BK-7 Glass)
• This is a reference value when film is deposited on a BK7 glass substrate and does not guarantee performance.
• The dynamic friction coefficient was determined by using nonwoven fabric (Clint paper) as the contact element.
• The refractive index is a fitted value obtained using an ellipsometer.
• ※ For Dev-01-001 and Dev-03-002, solvent resistance is obtained by heat treatment after film deposition.
Durability Test Method Details (PDF: 0.1MB)
Please feel free to contact us with any requests or inquiries regarding our products.
